1201 Hydraulic pressure gauge

Designation

Stainless steel case, crimped ring, liquid fillable

Model

Applications

Adverse service conditions where pulsation or vibration exists

Nominal size: (mm)

Ø(50, 63, 75, 100)

Scale ranges

- 1 to 600 bar

Accuracy class

2.5 Ø (40-50), 1.6 Ø (63-100)

Pressure connection

One piece sealing design 1/4" Ø(50, 63, 75, 100) 1/2" Ø(100)

Wetted parts

Copper alloy

Case material

Stainless Steel, crimped ring

Window

Polycarbonate or toughened glass

IP class

IP 65

Options/notes

Lower, back entry, Ø 63 and Ø100 with option of panel mount or surface mount
Refrigeration scale
