1100B Dry or utility pressure gauge

Designation

Standard gauge,steel case

Model

Applications

Gaseous and liquid media

Nominal size: (mm)

Ø40, 50, 63, 75, 100, 150, 200, 250

Scale ranges

-1+400barØ(40-250)

Accuracy class

2.5 Ø(40-75), 1.6 Ø(100-250)

Pressure connection

1/8" Ø(40) 1/4" Ø(50, 100) 1/2" Ø(100, 250)

Wetted parts

Copper alloy

Case material

Black steel case and bezel,fixed with screw

Window

Glass

IP class

IP 43

Options/notes

Model 1101 without bezel screw up to 100mm
Model + A : chrome plated bezel
Model + B : chrome plated case and bezel
Model + C : chrome plated case and connection
Lower or back entry,63 and 100 with option of panel mount or surface mount,40,50,63 with option of U-clamp with SS crimped ring
