1406 Stainless steel DIN case capsule low pressure gauge

Designation

Capsule low pressure gauge, Standard industrial series, Stainless Steel DIN bayonet ring

Model

1406

Applications

Gaseous and dry media

Nominal size: (mm)

Ø(100, 150)

Scale ranges

-600-0, 0-10 to 600mbar

Accuracy class

1.6Ø(100, 150)

Pressure connection

1/2"Ø(100, 150)

Wetted parts

Copper alloy

Case material

Stainless steel case, DIN bayonet ring

Window

Instrument glass

IP class

IP 54

Options/notes

Lower, back entry, or surface or panel mount
Model 1405 with black steel case
