1304 All stainless steel glycerin filled pressure gauge

Designation

Stainless steel Series, crimped ring, liquid fillable

Model

Applications

Gaseous, liquid, and corrosive media or corrosive environment

Nominal size: (mm)

Ø(63,100)

Scale ranges

-1 to 1000bar

Accuracy class

1.6 Ø(63)
1 Ø(100)

Pressure connection

One piece welded type1/4"Ø(63) 1/2"Ø(100)

Wetted parts

Stainless steel

Case material

Stainless Steel, crimped ring, w/groove on case

Window

Polycarbonate

IP class

IP 65

Options/notes

Groove on case, prepared for back flange
Lower, back entry, panel mount or surface mount
