MALE ADAPTER
Connects metric LF-Lok port to female ISO tapered thread
|
T TUBE |
PT-NPT FEMALE PIPE SIZE |
CATALOG NUMBER |
A |
B |
C |
E |
E1 |
|
3 |
1/8 |
TAM-3-1 |
29.4 |
13.15 |
12 |
4.0 |
1.8 |
|
6 |
1/8 |
TAM-6-1 |
32.8 |
15.75 |
12 |
4.6 |
4.6 |
|
6 |
1/4 |
TAM-6-2 |
38.1 |
15.75 |
14 |
4.6 |
4.6 |
|
8 |
1/4 |
TAM-8-2 |
39.1 |
16.50 |
14 |
6.3 |
6.3 |
|
10 |
1/4 |
TAM-10-2 |
39.9 |
17.50 |
14 |
7.7 |
7.7 |
|
10 |
3/8 |
TAM-10-3 |
40.6 |
17.50 |
17 |
7.7 |
7.7 |
|
10 |
1/2 |
TAM-10-4 |
45.2 |
17.50 |
22 |
11.9 |
7.7 |
|
12 |
1/4 |
TAM-12-2 |
46.5 |
23.50 |
14 |
7.1 |
9.1 |
|
12 |
3/8 |
TAM-12-3 |
46.5 |
23.50 |
17 |
9.1 |
9.1 |
|
12 |
1/2 |
TAM-12-4 |
51.8 |
23.50 |
22 |
11.9 |
9.1 |
|
18 |
1/2 |
TAM-18-4 |
53.2 |
24.90 |
22 |
11.9 |
13.9 |
|
18 |
3/4 |
TAM-18-6 |
53.2 |
24.90 |
27 |
15.9 |
13.9 |
All dimensions are in mullimeters unless otherwise specified, only for reference subject to change.
